Sonic Belt Tension Meter

Cheap price belt tension meter with measuring range of 0~750N for sale online. The tension meter has colored LED indications of High, Low, and OK. This belt tension tester measures belt tension by analyzing the harmonic characteristics of a vibrating belt.

SKU: CCHN-TM750

30-day Returns

Free Shipping

Delivery date: 6-25 days

Overview

Buy an CCHN belt tension meter with a measuring range of 0~750N, accuracy of ±5% of full-scale, resolution ±1N, belt width up to 36 mm, overload alarm 750N, Max. load 850N. The high accuracy belt tension meter is widely applied in industries of automobile, textile, cables, wires, plastic films, paper, and printing.

Specification

Model: CCHN-BTT2880
Measuring Range: 0-750N, 0-120lb, 0-77kg, 0-114seems
Total Error: ＜5%

Operating Temperature: 10℃~50℃
Transport Temperature: -5℃~70℃
Display: LCD

Units of Measurement: Hz/N
Power Supply: 4*1.5V AAA
Meter Size: 135*62*33mm

Dimension

Sonic belt tension meter dimension

Details

Belt Tension Meter Details

Applications

Tension meters are instruments that measure tension in cable, fiber, belts and webs, or sheets. CCHN tension meter mainly used in belt tension measurement can also be applied to measure the tension of objects such as tapes, and wires. Widely applied in industries of automobile, textile, cables, wires, plastic films, paper, and printing.

Sonic belt tension meter application

Tips: How does a tension meter work?

Tension Meter measures belt tension by evaluating the harmonic characteristics of a vibrating rope or belt. Ropes and belts, vibrate at a specific natural frequency based on their mass, tension, and length.
