24V High Pressure Peristaltic Pump, 42 mL/min Flow Rate

Peristaltic pump with 24 volt power supply for sale. This kind of high pressure peristaltic pump has a service life of 600-1500 hours. Peristaltic pump uses wear-resistant lubricating rod material.

Features:

• The width of high pressure peristaltic pump only 40mm, compact structure.
• 3 rollers low pulse design, compatible with tubing of wall 1mm.
• 24V peristaltic pump has certain corrosion-resistant application scenarios.
• The peristaltic pump body base is designed with strip mounting holes, which can be directly fixed to your equipment.

Specification:

• Model: CCHN-MN1A/ZL
• Rated Power: DC 12V, 24V
• Power: ≤3W
• Voltage RPM: 15 rpm, 150 rpm
• Tube Type: Silicone
• Flow Rate: 4.5 mL/min, 42 mL/min
• Net Weight: 100g
• Noise: ≤46 dB
• Outlet Pressure: ≤0.1 MPa
• Operating Environment: Temperature 0-60 ℃, relative humidity less than 85%

Dimension (Unit: mm)

Application:

Tips: Advanteges and Disadvantages of Precision Peristaltic Pump

Advantages:

• The only point of contact the pump has with the fluid or chemical is the interior of the tube.
• No valves or major seals to replace on a tube pump making them low maintenance.
• They are able to handle slurries, viscous chemicals, shear sensitive polymers and other abrasive fluids.

Disadvantages:

• The flexible hose or tube will tend to degrade with time and require periodic replacement.
• Replacing the hose can get expensive and timely do to the lubricant inside the casing (tube pumps are require less maintenance).
• With a hose pump at low flows the flow is pulsed. A hose pump is less suitable where a smooth consistent flow is required. An alternative type of positive displacement pump should be considered.
